Fuel architecture for 50 to 500 megawatt campuses.
We consult with contractors on turnkey fuel plants for 50 to 500 megawatt hyperscale and colocation campuses. The spec covers bulk storage, polishing, redundant transfer, day tanks, and generator-side fuel. We advise on design, operations strategy, and vendor selection. After award, those contractors install, service, and test so standby generators start clean when the grid does not. We specify and advise. We do not install the plant, dispatch tankers, or operate tanks.
We consult with contractors who deliver the fuel plant as a turnkey project: protected tanks, polishing skids, duplex transfer, and generator interface. We specify and advise. We do not install the plant, dispatch tankers, or operate tanks.
Four parts of the plant we specify: stored fuel, cleaned fuel, transferred fuel, and standby generators.
Bulk storage Polishing Transfer Standby power
Specified plant ranges
Typical ranges we specify for 50 to 500 megawatt campuses. Site conditions and applicable codes govern the final design.
Multi-million gallon underground UST and protected aboveground AST tank farms engineered to UL-2085. Features continuous interstitial leak detection, magnetostrictive level telemetry, and automated thermal vapor balancing.
- Design Standard
- UL-2085 / UL-142 Double-Wall
- Monitoring
- Continuous Interstitial Optical Probes
- Autonomy Window
- 48h – 120h Continuous Full-Load
- Containment
- 110% Net Secondary Impervious Dike
Automated closed-loop multi-stage filtration that recycles stored fuel. Laser particle counters, water coalescers, and magnetic traps down to 2 microns.
- Filtration Fineness
- 2-Micron Particulate + Water Separation
- Purity Standard
- Exceeds ISO 4406 Code 14/12/9
- De-watering
- Automated Sump Water Purge & Alerts
- Biocide / Stabilization
- Automated Metered Dosing Unit
Positive-displacement transfer skids with VFDs maintaining line pressure. Automatic lead-lag failover if a primary pump faults.
- Redundancy Architecture
- N+1 or 2N Dual Continuous Loops
- Pump Capacity
- 60 to 240 GPM Variable Frequency
- Failover Latency
- < 800 Milliseconds Automatic
- Valving
- Motorized Actuators with Manual Overrides
Dedicated double-wall day tanks for each generator block, with redundant floats and gravity-overflow return to bulk storage.
- Buffer Capacity
- 2 to 4 Hours Dedicated Run Time
- Sensory Float Array
- Quadruple Redundant Optical & Reed
- Emergency Overfill
- Zero-Pressure Gravity Return Run
- Fire Isolation
- Fusible-Link Thermal Shutoff Valves
Diesel and HVO100 generators for UPS and compute halls. Clean fuel for ignition without injector fouling.
- Ignition Readiness
- < 10 Seconds to 100% Block Load
- Fuel Cooling
- Integrated Return-Line Heat Exchangers
- Emissions Compliance
- EPA Tier IV Final with HVO100
- Governor Stability
- ± 0.25% Isochronous Frequency Control
WHY DCFS
Independent spec before the plant is awarded.
We specify turnkey fuel plants for data center campuses and help select the contractors who build and service them. We advise on architecture, operations strategy, and vendor selection. We do not install the plant.
Get in touch.
Tell us the campus. We will call you about the fuel-plant spec and contractors who can build it. To reach us now: (888) 555-FUEL
